Automotive Grade thin film flat chip resistors

Vishay Intertechnology, announced that the company has extended its TNPU e3 series of Automotive Grade ultra precision thin film flat chip resistors with a new space-saving component in the compact 0402 case size.

Offering excellent long term stability — for example, permitted maximum resistance change ≤ 0.05 % for 1000 hours at rated power P70 — the Vishay Draloric TNPU e3 series combines the proven reliability of the well-known TNPW series with lower temperature coefficients down to ± 5 ppm/K and tighter tolerances down to ± 0.02 % for increased accuracy. This unique combination makes the AEC-Q200 qualified resistors perfectly suited for applications such as operational amplifier circuits and sensors for test and measurement, automotive, industrial, medical, and telecommunications equipment.

With the addition of the 0402 case size, the Vishay Draloric TNPU e3 series is now available in 0402, 0603, 0805, and 1206 case sizes, with resistance values from 100 Ω to 511 kΩ. Offering superior moisture resistivity (85 °C; 85 % RH), sulfur resistance in accordance to ASTM B 809, and a wide temperature range of -55 °C to +125 °C, the resistors provide extremely stable operation that withstands even harsh environmental conditions.

TNPU e3 series components are suitable for processing on automatic SMD assembly systems and for automatic soldering using wave, reflow, or vapor phase. The resistors are RoHS-compliant, and their pure tin plating provides compatibility with lead (Pb)-free and lead (Pb)-containing soldering processes.

For more information log in to :  www.vishay.com
