Transmitter Controller ICs for Inductive Wireless Charging

Infineon Technologies AG (FSE: IFX / OTCQX: IFNNY) launched the WLC1115 transmitter controller ICs: the first product of the new WLC family of controllers for inductive wireless charging. WLC1115 comes along with a Qi v1.3.2 certified MP A11 power transmitter reference solution, targeting various applications, including smartphones, smart speakers, docking stations, monitor stands, as well as industrial or healthcare accessories.

“The WLC1115 transmitter controller IC and companion reference design for wireless charging is the ideal choice for a wide range of consumer and industrial applications that demand state-of-the-art Qi-standard compliance,” said Ajay Srikrishna, Senior Vice President and General Manager of the Wired Connectivity Solutions Product Line at Infineon. “As inductive wireless charging standards evolve, our programmable solution will offer the flexibility to scale higher power levels and allow OEMs to materialize differentiated features while remaining Qi-compatible.”

Infineon’s WLC1115 is a highly integrated, Qi-compliant, and fully configurable 15 W transmitter controller IC for wireless charging solutions. It includes a USB-PD/PPS sink, DC/DC controller, gate drivers for DC/DC, a full-bridge inverter, sensing peripherals, and configurable flash memory. WLC1115 supports a wide input voltage range from 4.5 V to 24 V, multipath voltage- and current-based ASK demodulation. Additionally, the controller features an integrated, programmable, high-side current-sense amplifier and adaptive Foreign Object Detection (FOD) via Q-factor, resonant frequency, and power loss. It also includes comprehensive protection features for UVLO, OVP, OCP, and OTP that are programmable.

The WLC1115-based Extended Power Profile (EPP) transmitter solution using OPTIGA™ Trust Charge meets the authentication requirements as specified in the Qi v1.3.2 standard. Combined with Infineon’s comprehensive offering for USB-C chargers and broad MOSFET portfolio, the WLC1115 solution offers a complete product package that can help meet the stringent regulatory and compliance requirements. Moreover, it is accompanied by software tools that support Qi v1.3.2 and proprietary charging protocols.

Availability

The Infineon WLC1115 transmitter controller ICs are available now. More information about the chipset and reference designs are available at www.infineon.com/wirelesscharging-ics and www.infineon.com/ref-wlc-tx15w-c1
